在設備系統中我們通常可以分為：攝像顯像系統，影像記錄系統，光源系統，人工氣腹系統，液體加壓系統，電凝電切系統，動力消融系統，沖洗吸引系統等等。下面內窺鏡維修公司詳細為您解說。

In the equipment system, we can generally divide it into: camera imaging system, image recording system, light source system, artificial pneumoperitoneum system, liquid pressurization system, electrocoagulation and electrosurgical system, dynamic ablation system, irrigation and suction system, etc. The endoscope maintenance company will give you a detailed explanation.

（1）攝像顯像系統：該系統包括顯示器和攝像機。顯示器有常規的CRT和液晶兩種，攝像機有單CCD和3CCD兩種。現在高端的使用客戶多是液晶顯示器配3CCD攝像器。

(1) Imaging system: the system includes a display and a camera. There are conventional CRT and LCD displays, and single CCD and 3CCD cameras. At present, most of the high-end users are LCD with 3CCD camera.

（2）影像記錄系統：現在很多醫院都選擇以電腦為基礎的圖文工作站。該系統分兩部分：電腦硬件和圖文采集軟件。

(2) Image recording system: many hospitals now choose computer-based graphic workstation. The system is divided into two parts: computer hardware and graphics acquisition software.

（3）光源系統：又稱冷光源。冷光源燈泡中充有鹵素和氙氣兩種，其輸出功率為70-400W。現在300W氙光源是主流的產品。其突出特點是光線強烈，色溫5600-6000k，與太陽光類似，涵蓋了從紫外線到紅外線的整個波段。

(3) Light source system: also known as cold light source. The cold light source bulb is filled with halogen and xenon, and its output power is 70-400w. Now 300W xenon light source is the mainstream product. It is characterized by strong light and color temperature of 5600-6000k, which is similar to sunlight and covers the entire wavelength band from ultraviolet to infrared.

（4）人工氣腹系統：將氣腹機與二氧化碳鋼瓶連接好，并旋開鋼瓶上的閥門，然后開啟氣腹機，根據手術的需要，選擇壓力預設值，當腹腔內壓力超過或低于設定值時，全自動二氧化碳氣腹機可自動開始或停止注氣。

(4) Artificial pneumoperitoneum system: connect the pneumoperitoneum machine with the carbon dioxide cylinder, unscrew the valve on the cylinder, and then open the pneumoperitoneum machine. According to the needs of surgery, select the preset pressure. When the pressure in the abdominal cavity exceeds or is lower than the set value, the full-automatic carbon dioxide pneumoperitoneum machine can automatically start or stop gas injection.

（5）液體加壓系統：關節泵、膨宮泵和膀胱泵等系統主要是用于通過液體加壓成腔，然后再通過器械在腔體內進行手術。

(5) Liquid pressurization system: Joint pump, dilation pump, bladder pump and other systems are mainly used to pressurize the cavity through liquid, and then perform surgery in the cavity through instruments.

（6）電凝電切系統：在普通開放性手術中和微創手術中都常使用高頻電刀。

(6) Electrocoagulation and electrosurgical system: high frequency electrosurgery is often used in ordinary open surgery and minimally invasive surgery.

（7）動力消融系統：在鼻竇鏡和關節鏡手術中多會使用的是動力刨削系統和離子消融刀，這兩種設備雖然價格不菲，但是它們卻大大地縮短了術中時間和降低了手術風險。

(7) Power ablation system: power planing system and ion ablation knife are often used in sinus surgery and arthroscopic surgery. Although these two devices are not cheap, they greatly shorten the operation time and reduce the operation risk.

（8）沖洗吸引系統：設備沖洗流速少應達到1L/min。

(8) Flushing suction system: the equipment flushing flow rate shall be less than 1L / min.

醫用內窺鏡系統通常可以分為什么的問題就講解到這里了，使用前后記得檢查該設備是否有問題存在，以免在使用中造成不好的影響，關注我們http://m.cnxgtzyj.cn帶您認識更多注意事項！

The medical endoscope system can usually be divided into the following problems. Before and after use, remember to check whether there are problems with the equipment to avoid adverse effects in use. Pay attention to us http://m.cnxgtzyj.cn Take you to know more precautions!
